Lithe Audio Micro Wireless Subwoofer

Lithe Audio Wireless Micro Subwoofer

Big Impact from a compact subwoofer, this Sub is equipped with Chromecast and Apple AirPlay2. Connect this wirelessly to your Lithe multi-room audio system or other compatible setups and add the bass to your music.

Augmented Reality

It's important that you know what your speakers will look like, so we've made something you can interact with.

Tap the AR icon and see the Micro Sub in your room.

Micro Sub. Mighty Bass.

The perfect accompaniment to your existing home audio system. With Chromecast and Alexa compatibility, you’re only a few steps away from experiencing awe-inspiring audio, right from the comfort of your living room.

Quick & Easy Setup

Quick and easy setup, plug-in and sync to home Wi-Fi network and group with any existing speakers.

Multi-Room Wireless Connectivity

Setup the micro sub anywhere without the restrictions of speaker cable.

Works With Any Brand Of Google Cast Speaker

Group with any brand of speaker which has Google Cast to create a multi-brand multi-room audio setup.

Ethernet Hardwired Connection

Data in and Data out for streamlined cable management and a rock-solid data connection.

App-Based DSP

Full control over the crossover frequency, phase, volume, gain, low & high pass filter with presets.

High-Quality Audio

Blends high power with 1x active and 2x radiator 4” drivers to deliver immersive bass with ease.

Perfect For:

All-in-one solution makes these unique speakers perfect for kitchens, bedrooms, extensions, home offices and hotel rooms.

• Kitchen: Background music system
• Dining: Listen to your latest podcast
• Bedrooms: Make magic happen
• Home Office: Work to the sound of music
• Guest Room: Something for the guests
• Working Out To: Set the pace with your favourite tunes
• Dancing: Dance like no one is watching
• Open Plan Living: Big space? No problem

The Technical Bit

Simple to install diagram via a plug socket. Setup from your phone and connect via the Lithe Audio App or to your Smart Home systems such as Control4, Loxone and Fibaro.

Features

• Plug & Play
• Wireless connectivity
• Works with any Google Cast speaker
• Ethernet hardwired connection
• App based DSP
• High quality audio
• App control via iOS or Android, full control with easy drag and drop zoning

Speaker

• Sound Quality THD+N <0.009%, 40 Hz - 200 Hz @ -10 dB
• RMS Power: 50 W @ 4 ohm load
• Sensitivity (1 W / 1 m): 90 dB
• Type: Class D (digital)
• Audio compression: 192 kHz / 24 bits
• Woofer: 4” polypropylene driver / 2 x 4” passive radiator

Music Access

• Audio formats supported: MP3, WMA, AAC (MPEG4), AAC+, ALAC, FLAC, APE, WAV, OGG, LPCM
• Audio sample rate: Up to 192 kHz 24 bit
• Music services supported by Lithe Audio include; Airable Radio, Podcast, TIDAL, Deezer, Soundmachine, Amazon Music, Napster, Spotify, etc.
• Operating systems (for stored files) Windows XP SP3 and higher; Mac OS X 10.6.8 and higher; NAS (Network Attached Storage) devices supporting CIFS

General

• 50/60 Hz / 3 A
• Output supply : DC 24 V / 3 A >5 mins.
• DC 24 V / 5 A Peak power >10 s
• Dimensions (W x D) 174 x 174 mm (6.85 x 6.85 in)
• Weight 3 kg (6.61 lbs)
• Operating temperature 0º to 40º C (32º to 104º F)
• Storage temperature -20º to 70º C (4º to 158º F)
• Standby power: 1.3 W / 0.02 A
• Connected power: 1.5 W / 0.03 A
• Playing music: 2.8 W - 10.5 W / 0.03 A - 0.09 A

Wireless Networking

• Expandable up to 30 speakers within same Wi-Fi network
• Wi-Fi Connectivity: Wi-Fi Certified™ 802.11 b/g/n/ac, WPA™, Personal WPA2™, Personal WMM®, Wi-Fi Protected Setup™
• Wireless connectivity works on your home Wi-Fi network with both 2.4 GHz/5 GHz broadcast routers
• Internet connection required for access to internet radio stations, online music services and software updates
• Recommended routers: Archer MR600 (TP-Link), UDM (Ubiquiti) and 2866AC-K (Draytek)

What's In The Box

• Subwoofer
• Power cord
• Instruction manual
